Scntoc Resolution Manager 1.0 released !

Posted by Administrator | Posted in General, pyQt, Python, SoftImage XSI | Posted on 06-03-2013

0

I have recently written an application in pyQt called ‘Scntoc Res Manager’. This application let’s you open, inspect, modify a scntoc file. Scntoc files are generated for each .scn file, the format for Autodesk Softimage scene files. It is a very useful utlitity that lets you modify contents of a softimage file with openging Softimage. With this application you can quickly, easily and efficiently change the active resolutions of referenced models in a scene.

The project is hosted at git hub here.

The zip file is available here.

For cloning the repo through git bash, use:

git clone https://github.com/alok1974/scntocResManager.git



Here is a small demo video of the application:

Hope you enjoy it.

Barycentric Coordinates and the Magic of Locations

Posted by Administrator | Posted in ICE, Math, SoftImage XSI | Posted on 28-05-2012

4

Barycentric Coordinates is a type of coordinate system to define the coordinates of an entity in “n-dimensional space” (for CG it is 3 dimensions). One of the interesting properties of this coordinate system is that it is affine and depends on the object space.

Barycentric Coordinates were formulated  by Mobius (who is also known for the famous Mobius strip) in 1827.

This coordinate system bears significant importance specially in Computer Graphics but it can be a daunting task to understand fully the concept of Barycentric Coordinates for not so mathematically inclined.

So in this post, I will try to explain in the simplest terms, what Barycentric Coordinates are and how they are used in Computer Graphics.

As is the case with many other DCC Applications, Barycentric Coordinates are exploited to a great extent in Softimage. Although I have no official proof, but I can most safely say that the Location Data we so much love and use in ICE are nothing but an implementation of Barycentric Coordinates.

To begin with, let us make things simpler and life easier (that’s my favorite mantra). Consider a triangle.

If I was asked to find a point on this piece so that it could be balanced perfectly on a point of pencil, what would I do? A little bit of intuition would suggest taking the central point of the triangle.



That is all correct, but let’s now complicate things a little bit. If the shape of the piece is an irregular triangle with all sides having different lengths then the central point is not easier to guess.

I would solve this by applying a little geometry and divide each side in half and connect the opposite vertex of the triangle to these points. The lines thus created will yield the central point and I will be able to balance the triangle on that point with the pencil.

All good, now let us raise the bar some more and tie some weights to each vertex of the triangle. There are different weights on each vertex. Now the task of finding a point at which the triangle can be balanced is no more pure geometry. I have to consider that each of these weights is pulling the triangle with different forces.



This is where the Barycentric Coordinates can be applied to find the answer. In fact, the word barycentre originates from the Greek root “barus” which generally refers to weighty or heavy.

So to solve our problem we should divide each side of the triangle in the same ratio as the weights in the vertex forming that side, as shown below.

After getting this three points, it is just of matter of connecting this points to the opposite vertex and bingo! We have our balancing point:

What we just did was to find the Barycentric coordinates of the point with given weights at the vertices.

We can also write this as:



Where P is our bary centric point and A, B and C are the weights at the vertex. 10 comes from adding the three weights 2 + 3 + 5. Also note that:





So now that we have the notion of bary center, let us see how this relates to CG coordinates with vector geometry. We know that any triangle in the 3D Coordinate system can be defined as (x1, y1, z1), (x2, y2, z2), (x3, y3, z3) representing the x, y, z coordinates of each vertex. Also in vector notation this can be written as, A, B, C where A, B and C are the vectors defining the point positions (vertices) of the triangle.



Let P be any arbitrary point on the triangle, then P can always be defined with the help of vectors A, B and C as :



Where,



Here ,



are called the Barycentric coordinates (remember these are just three real numbers for a triangle).



So now we totally understand the notion as well as the mathematical representation of Bary Centric Coordinates. How do we use it to make life easier in the CG World?

There are numerous ways to use them, but here I will discuss the locations in Softimage which are available both in ICE and the API methods.

The whole idea of locations magically following the mesh (or sticking to location) happens in the following way:

  1. First a point on the triangle is found which will be used as initial location. This can be done in many ways, raycasting is one of them. We throw a ray from a certain point, in a well defined direction towards the triangle. The point where the ray hits(intersects) with the triangle is determined.
  2. Once the coordinates(vector) of the point on the triangle is known, Barycentric coordinates this point are calculated (this calculation is not very hard, but still requires some mathematical knowledge, so I am skipping them for the purpose of being simple).
  3. Once we know the Barycentric coordinates for this point, we can simply get this point at any point of time just using the three position vectors of the triangle.
  4. In this way, even when the triangle is deformed in any way, we always know our point, in other words the location of the point sticks to the triangle.
  5. For example, after doing a ray cast we find that barycentric coordinates for the location are (0.35, 0.25, 0.40). These will be fixed throughout the simulation/animation/mesh move. After the triangle has been transformed, to get our location, we have to simply get the vectors for the point position at this point and multiply them by the scalars 0.35, 0.25 and 0.40, add the result. This will give a new vector, which is our location.

This ICE Tree exhibits the barycentric coordinates in action. Even if you move the point of the triangle, the point will always lie in the triangle.



Download Scene File here. In the softimage scene, move the vertices of the triangle and you will see that the location represented by the red sphere will remain on the triangle:



I hope that now you have a better idea of what bary centric coordinates are. Please feel free to ask questions about this on alokdotgandhiatgmaildotcom

Convex Hull : ‘Maths can be fun’

Posted by Administrator | Posted in Math, Python, SoftImage XSI | Posted on 17-04-2011

4

I always strive to break the mantle of sophistication that is so attached with mathematics. In fact in all of sciences, if the fundamentals are understood clearly, in simple terms, it is easy for anybody to understand the advance concepts. But we have to have a solid fundamental base to start with. I always maintain that if we can learn the 26 alphabets of English, we can learn almost anything !!

Recently, I am working on creating a new algorithm for finding the convex hull from a given set of 2d points in plane. In this post, we will discover the  concept of convex hull. It will be a fun ride, believe me. In fact the method that I devised for finding the convex hull is so easy that even a six year old can do it given a piece of paper and pencil.



So first thing first, what is a Convex Hull ?



Convex Hull

If we keep ourselves restricted to the computational geometry and 2 dimesions:



Convex Hull can be defined as the boundary polygon for a given set of points.



It is more clear from the illustration below.



You can also imagine the convex hull by following analogy. Consider this points as nails on a piece of wood. If you were to wrap a rubber band around these nails, it will snap to the boundary nails. The shape of the rubber band represents the convex hull for the given nail positions.



The convex hull has numerous application in CG. Namely, better bounding boxes for meshes, bsp calculations for render times, finding projection areas to drive asset resolutions and numerous other. Creativity has no bounds, you can use convex hulls to do many things, use your imagination.



Let’s  start,

Suppose we have a set of points in a given 2D plane. We want to find out a way to find all the points that define the boundary of all the given points.



As I said, it is going to be fun. Let us start with a few random points in a 2d plane. We assign a name to each of this points.

Looking at the figure above, we prepare two list of these points. First, going to from left to right, we take the left most point, and then the next left most point and so on, then we make another list going from top to bottom for the same points.



These are the two list that we will have:



Left to Right      : [f, j, d, a, b, h, l, m, c, g, i, e, k]

Top to Bottom  : [h, m, e, j, a, c, b, k, f, i, g, d, l]



The cool thing now is we have all the information we need to process the convex hull. Just grab a paper and pencil and play with these list according to the rules of game I define below. In fact what we will be doing from now is the gist of my algorithm. Remember, we are working with alphabets, so no calculations are needed, not even an addition. It is so simple. Even the alphabets do not represent any order. They are just a bunch of symbols to distinguish between the points,  you can use smileys if you want instead !! and it will still work. We also don’t need to look at the figure even. Just the lists.



OK, so let’s start the game, here’s how we play:



We start from the Left-Right list. We take the first element of this list. In this ‘f’. This definitely is a border point. So our first point of the convex hull is ‘f’.



Convex Hull = [f, ]



Next we look at the point next to ‘f’ in the Left-Right list, it is ‘j’. Now we should see whether ‘j’ also comes after ‘f’ in the Top-Bottom list. No. So we move to the next point in the our Left-Right list, it is ‘d’. Does ‘d’ comes after ‘f’ in the Top-Bottom list. Yes it does. So check-in this point next in our convexHull,



Convex Hull = [f, d, ]

As soon as we check-in a point in the Convex Hull list. We should remove the previous ‘f’ from the Left-Right and Top-Bottom lists. So these now become.



Left to Right      : [ j, d, a, b, h, l, m, c, g, i, e, k]

Top to Bottom  : [h, m, e, j, a, c, b, k, i, g, d, l]



So our focus now moves to ‘d’. What is the next point after ‘d’ in the Left-Right list. ‘a’. Does ‘a’ comes after ‘d in the Top-Bottom list. No. So we move on, till we reach ‘l’. This comes after ‘d’ in both Left-Right and Top-Bottom list and so this is a convex hull point.

Convex Hull = [f, d, l, ]



again we remove remove previous point ‘d’ from both the lists,



Left to Right      : [ j, a, b, h, l, m, c, g, i, e, k]

Top to Bottom  : [h, m, e, j, a, c, b, k, i, g, l]



Now as we have reached the last point of the Top-Bottom list. We can no longer check whether there are any point after it. Whenever we reach a last point in any of the list. We should switch the list and change direction. Since we have reached ‘l’, which is the last point of the Top-Bottom list, we should now start looking for points in the Top-Bottom list but in the reverse direction. So what point comes before ‘l’ in the Top-Bottom list. ‘g’, does ‘g’ also comes after ‘l’ in the Left-Right list, yes. So we check in ‘g’ to the Convex Hull.



Convex Hull = [f, d, l, g]



removing ‘l’ we get,

Left to Right      : [ j, a, b, h, m, c, g, i, e, k]

Top to Bottom  : [h, m, e, j, a, c, b, k, i, g]



You get the idea, again, continuing in the same fashion we will have the convex hull as :

Convex Hull = [f, d, l, g, i, k]



and the lists as :

Left to Right      : [ j, a, b, h, m, c, e, k]

Top to Bottom  : [h, m, e, j, a, c, b, k]

when we reach ‘k’, this is last element in Left-Right list. So according to our rules, we switch the lists and start to look in the reverse in Left-Right list.  At this moment we are looking in both the lists in the reverse directions remember. So the point before ‘k’ in Left-Right list is ‘e’, does it also come before ‘k’ in the Top-Bottom list, the answer is yes and so we check in ‘e’ in the convex hull and remove the previous point ‘k’ from the list,

Convex Hull = [f, d, l, g, i, k, e]

Left to Right      : [ j, a, b, h, m, c, e]

Top to Bottom  : [h, m, e, j, a, c, b]



movng in the same fashion in both the lists we have,



Convex Hull = [f, d, l, g, i, k, e, m, h]

Left to Right      : [ j, a, b, h, c]

Top to Bottom  : [h,  j, a, c, b]



‘h’ being the first point of the Top-Bottom list, we again switch the lists and look in the Top-Bottom list in the forward direction, while reverse in the Left-Right list. And we keep on going to find the same patterns of occurance, we are almost there,



in the Top-Bottom list the element next to ‘h’ is ‘j’. Does ‘j’ comes before ‘h’ in the Left-Right list. Yes, so we check in ‘j’ and remove ‘h’ from the lists. At this point we stop. Why ? because we have reached where we started, the first element of the Left-Right list. So our convex hull at this point look like.



Convex Hull = [f, d, l, g, i, k, e, m, h, j]



Let’s draw our hull and check what we have,





Not bad, without any calculation. But we have a few concave points still inside. These are ‘g’ , ‘i’ and ‘m’. These points might or might not  appear in the hull depending upon the uniqueness of our data set. But we should always as a final step remove these out of our way. To do this we take three points of the hull at a time and check for convexity. Please refer to my post for more details finding convex points.

So we take three point sets from the hull in the order they appear, like ‘fdl’, ‘dlg’, ‘lgi’ and so on and so forth and remove all the concave points, we call this a single iteration. We do a few iterations of the same logic till we have no more convex points left.

This is how these points are removed in the iteration :

First Iteration : ‘i’ is removed from ‘gik’, ‘m’ is removed from ‘emh’.



Second Iteration : ‘g’ is removed from ‘lgk’.





And lo! we finally have our convex hull as:



Final Convex Hull = [  f, d, l, k, e,  h, j  ]



Let’s use our algorithm inside Softimage to find the convex hull for meshes. To use the algorithm, we use a python implementation of the algorithm and feed to it the position array of a mesh. We create a curve based on the convex hull. Just select any mesh and run the below code. It will create a curve representing the convex hull.



Note that as we are in 2D plane, we get the hull as we see the points in front view. Even if you rotate, translate or scale the mesh, the hull will still be created at the current position array. To create the hull for a different view of the mesh, select the points of the mesh and then rotate, scale or transform them. After applying your transformations to the mesh points, freeze the mesh.



Here are a few screen shots.



Please note that for the implementation of the algorithm in python, I am not using any optimizing techniques. This code creates a convex hull for 15000 mesh points in about 6 seconds. To deploy this as a production ready solution, I would use numpy, cython or build my own extensions written in c/c++ for performance enhancement and better memory management to handle a few million points. Since that is beyond the scope of this post, so let’s not discuss it.

This  is the  implementation:

from win32com.client import constants as c
import random

def printOnOff(inStr):
    printIt = False
    if printIt:
        print inStr
    else:
        pass

    return

def makeNulls(xCoords, yCoords, sortedPoints,curve):

    nbPoints = len(xCoords)
    mdl = Application.ActiveSceneRoot.AddModel(None,'randomPoints')
    mdl.Properties('Visibility').Parameters('viewvis').Value = False

    points = mdl.AddNull('points')
    points.Properties('Visibility').Parameters('viewvis').Value = False

    if curve:
        points.AddChild(curve)

    for i in range(nbPoints):
        if i < 10:
            zeros = '000'
        elif i < 100:
            zeros = '00'
        elif i < 1000:
            zeros = '0'
        else:
            zeros = ''

        null = points.AddNull('point_%s%s'%(zeros, i))
        null.Kinematics.Global.Parameters('PosX').Value = xCoords[i]
        null.Kinematics.Global.Parameters('PosY').Value = yCoords[i]
        null.Kinematics.Global.Parameters('PosZ').Value = 0
        null.Parameters('primary_icon').Value = 0
        null.Parameters('shadow_icon').Value = 5
        null.Parameters('shadow_colour_custom').Value = True

        if i in sortedPoints:
            r = 0.0
        else:
            r = 1.0

        null.Parameters('R').Value = r
        null.Parameters('G').Value = 1.0
        null.Parameters('B').Value = 0.0

    return

def createRandomPoints(nbPoints=20):
    xCoords = []
    yCoords = []
    for i in range(nbPoints):
        xRand = nbPoints * random.random() #* random.randint(1,3)
        yRand = nbPoints * random.random() #* random.randint(1,3)

        x = random.uniform(-1 * xRand, xRand)
        y = random.uniform(-1 * yRand, yRand)

        xCoords.append(x)
        yCoords.append(y)

    return xCoords, yCoords

def makeOrderedTuples(xCoords, yCoords):
    data = None
    nbPoints = len(xCoords)
    xCoordsTuples = []
    yCoordsTuples = []
    for i in range(nbPoints):
        xRand = nbPoints * random.random() #* random.randint(1,3)
        yRand = nbPoints * random.random() #* random.randint(1,3)

        x = xCoords[i]
        y = yCoords[i]

        xCoordsTuples.append((x, i))
        yCoordsTuples.append((y, i))

    sortedXIndex = []
    sortedXIndex = [ xTuple[1] for xTuple in sorted(xCoordsTuples,
                                                   key=lambda xCoord: xCoord[0])]

    sortedYIndex = []
    sortedYIndex = list(reversed([ yTuple[1] for yTuple in sorted(yCoordsTuples,
                                                  key=lambda yCoord: yCoord[0])]))

    data = xCoordsTuples, yCoordsTuples, sortedXIndex, sortedYIndex

    return data

def makeCoordString(coords):
    xCoords, yCoords,zCoords = coords
    pStr = ''
    nbPoints = len(xCoords)
    for i in range(nbPoints):
        pStr += '('
        pStr += str(xCoords[i])
        pStr += ','
        pStr += str(yCoords[i])
        pStr += ','
        pStr += str(zCoords[i])
        pStr += ')'
        if i != nbPoints - 1:
            pStr += ','

    return pStr

def makeCurve(pStr):
    curve = Application.CreateCurve( 1, 0, pStr)('Value')
    curve.Name = 'convexHull'
    Application.ApplyTopoOp('CrvOpenClose', curve, 3, c.siPersistentOperation)
    Application.FreezeObj(curve)
    #curve.Properties('Visibility').Parameters('selectability').Value = False

    return curve

def isConvex(pointA, pointP, pointB):
    x1, y1 = pointA

    x2, y2 = pointB

    x3, y3 = pointP

    quadB = 0

    if x2 > x1 and y2 > y1:
        quadB = 0
    elif x2 < x1 and y2 > y1:
        quadB = 1
    elif x2 < x1 and y2 < y1:
        quadB = 2
    elif x2 > x1 and y2 < y1:
        quadB = 3

    y = y1 + ((x3 - x1) * (y2 - y1) / (x2 - x1))

    if quadB == 0 or quadB == 3:
        if y > y3:
            return 1
        else:
            return 0
    elif quadB == 1 or quadB == 2:
        if y > y3:
            return 0
        else:
            return 1

def getConvexHull(xCoords, yCoords):
    xCoords, yCoords, sortedX, sortedY = makeOrderedTuples(xCoords, yCoords)
    startPoint = sortedX[0]
    firstPoint = startPoint
    sortedPoints = [firstPoint]
    inflection = 0
    normalInflection = False
    inflectionPoints = []
    nextPoint = 0
    nbPoints = len(sortedX)
    for i in range(nbPoints):
        yIndexOfFirstPoint = sortedY.index(firstPoint)
        xIndexOfFirstPoint = sortedX.index(firstPoint)
        for xIndex in range(xIndexOfFirstPoint + 1, nbPoints):
            pointToCheck = sortedX[xIndex]
            yIndexOfPointToCheck = sortedY.index(pointToCheck)
            if yIndexOfPointToCheck > yIndexOfFirstPoint:
                nextPoint = pointToCheck
                sortedPoints.append(nextPoint)
                if yIndexOfPointToCheck + 1 == nbPoints:
                    printOnOff('First Inflection at %s !!'%nextPoint)
                    inflectionPoints.append(nextPoint)
                    inflection += 1
                    normalInflection = True
                break
        if inflection == 1:
            break

        firstPoint = nextPoint

    if not normalInflection:
        printOnOff('First Inflection at %s - Abnormal!!'%firstPoint)
        inflection += 1

    normalInflection = False
    firstPoint = nextPoint
    for i in range(nbPoints):
        xIndexOfFirstPoint = sortedX.index(firstPoint)
        yIndexOfFirstPoint = sortedY.index(firstPoint)
        for yIndex in range(yIndexOfFirstPoint -1, -1,-1):
            pointToCheck = sortedY[yIndex]
            xIndexOfPointToCheck = sortedX.index(pointToCheck)
            if xIndexOfPointToCheck > xIndexOfFirstPoint:
                nextPoint = pointToCheck
                sortedPoints.append(nextPoint)
                if xIndexOfPointToCheck + 1 == nbPoints:
                    printOnOff('Second Inflection at %s !!'%nextPoint)
                    inflectionPoints.append(nextPoint)
                    inflection += 1
                    normalInflection = True
                break
        if inflection == 2:
            break

        firstPoint = nextPoint

    if not normalInflection:
        printOnOff('Second Inflection at %s - Abnormal!!'%firstPoint)
        inflection += 1

    normalInflection = False
    firstPoint = nextPoint
    for i in range(nbPoints):
        yIndexOfFirstPoint = sortedY.index(firstPoint)
        xIndexOfFirstPoint = sortedX.index(firstPoint)
        for xIndex in range(xIndexOfFirstPoint - 1, -1,-1):
            pointToCheck = sortedX[xIndex]
            yIndexOfPointToCheck = sortedY.index(pointToCheck)
            if yIndexOfPointToCheck < yIndexOfFirstPoint:
                nextPoint = pointToCheck
                sortedPoints.append(nextPoint)
                if yIndexOfPointToCheck == 0:
                    printOnOff('Third Inflection at %s !!'%nextPoint)
                    inflectionPoints.append(nextPoint)
                    inflection += 1
                    normalInflection = True
                break
        if inflection == 3:
            break

        firstPoint = nextPoint

    if not normalInflection:
        printOnOff('Third Inflection at %s - Abnormal!!'%nextPoint)
        inflection += 1

    printOnOff('\n\n\n')
    normalInflection = False
    firstPoint = nextPoint
    for i in range(nbPoints):
        xIndexOfFirstPoint = sortedX.index(firstPoint)
        yIndexOfFirstPoint = sortedY.index(firstPoint)
        for yIndex in range(yIndexOfFirstPoint + 1, nbPoints):
            pointToCheck = sortedY[yIndex]
            xIndexOfPointToCheck = sortedX.index(pointToCheck)

            if xIndexOfPointToCheck < xIndexOfFirstPoint:
                if pointToCheck in sortedPoints:
                    printOnOff('Final Point %s added !!'%firstPoint)
                    inflection += 1
                    normalInflection = True
                    break
                #printOnOff('breaking out . . . ')
                nextPoint = pointToCheck
                sortedPoints.append(nextPoint)
                break
        if inflection == 4:
            break

        firstPoint = nextPoint

    if not normalInflection:
        printOnOff('Fourth Inflection at %s - Abnormal!!'%nextPoint)
        inflection += 1

    printOnOff('\n\n\n')
    printOnOff('No. of Inflections : %s'%inflection)

    sortedXCoords = [ xTuple[0] for xTuple in sorted(xCoords,
                                                  key=lambda xCoord: xCoord[1])]

    sortedYCoords = [ yTuple[0] for yTuple in sorted(yCoords,
                                                  key=lambda yCoord: yCoord[1])]

    printOnOff('Inflection Points : %s'%inflectionPoints)

    filterConcave = True
    if filterConcave:
        noConcaveLeft = False
        filteredPoints = sortedPoints
        while not noConcaveLeft:
            nbFilteredPoints = len(filteredPoints)
            concavePoints = []
            for i in range(nbFilteredPoints):
                if i == nbFilteredPoints - 1:
                    break

                j = i + 1
                if i == nbFilteredPoints - 2:
                    k = 0
                else:
                    k = i + 2

                indexStartPoint = filteredPoints[i]
                indexMiddlePoint = filteredPoints[j]
                indexEndPoint = filteredPoints[k]

                startPoint = (sortedXCoords[indexStartPoint], sortedYCoords[indexStartPoint])
                middlePoint = (sortedXCoords[indexMiddlePoint],
                                       sortedYCoords[indexMiddlePoint])
                endPoint = (sortedXCoords[indexEndPoint], sortedYCoords[indexEndPoint])

                if not isConvex(startPoint, middlePoint, endPoint):
                    concavePoints.append(indexMiddlePoint)

            if not len(concavePoints):
                noConcaveLeft = True

            for point in filteredPoints:
                if point in concavePoints:
                    filteredPoints.remove(point)

        sortedPoints = filteredPoints

    makeConvexHullCurve = True
    curve = None
    if makeConvexHullCurve:
        nbBorderPoints = len(sortedPoints)

        xSortedPoints = [sortedXCoords[i] for i in sortedPoints]
        ySortedPoints = [sortedYCoords[i] for i in sortedPoints]
        zSortedPoints = [0.0 for i in range(nbBorderPoints)]

        coordsForString = (xSortedPoints, ySortedPoints, zSortedPoints)

        pStr = makeCoordString(coordsForString)
        curve = makeCurve(pStr)

    return sortedPoints, curve

def createHullFromSelectedMesh():
    mesh = Application.Selection(0)
    if not mesh or mesh.Type != 'polymsh':
        Application.LogMessage('Invalid Selection !!!\nPlease select a polymesh.', 2)
        return
    geom = mesh.ActivePrimitive.Geometry
    points = geom.Points
    posArr = points.PositionArray

    xCoords = list(posArr[0])
    yCoords = list(posArr[1])
    sortedPoints, curve = getConvexHull(xCoords, yCoords)
    curve.Name = 'convexHull%s'%mesh.FullName
    mesh.AddChild(curve)

    printOnOff('Convex Hull Created Successfully')

    return

def createHullFromRandomPoints(nbPoints = 100):
    xCoords, yCoords = createRandomPoints(nbPoints)
    sortedPoints, curve = getConvexHull(xCoords, yCoords)
    makeNulls(xCoords, yCoords, sortedPoints, curve)
    printOnOff('Convex Hull Created Successfully')

    return

#--------------------------------------------------------------------------
# If you wish test the algorithm on a random points then set the flag
#
# hullFromMesh = False
#
# else the hull will be created from the selected mesh
#
# This will create a bunch of random point and claculate the hull on these
# points. You can set the total number of points with the variable
# nbPoints.
#
# If you care for data logged out of algorithm then set the flag
# printIt = True in the top most function printOnOff. It is off by default.
#-------------------------------------------------------------------------

hullFromMesh = True

if hullFromMesh:
    createHullFromSelectedMesh()
else:
    createHullFromRandomPoints(nbPoints=100)



Enjoy

Testing a point inside triangle : ‘Math at work in CG’

Posted by Administrator | Posted in Math, Python, SoftImage XSI | Posted on 16-04-2011

0

Here we discuss ways to derive and implement the logic for testing a point inside triangle. In other words we define a system for which given three points as the vertex of a triangle, we find whether a point lies inside the triangle or not. For the purpose of simplicity, we will confine these test in a 2d coordinate system.

If this post seems longer to you, then believe me, if you follow it patiently to the end, you will see that to make it simple I have to be more descriptive, sometimes even verbose. I would say, it is easy to be hard but very hard to be easy !!!

Back to High School

Before approaching any logic/methodology we first examine the fundamentals of mathematics involved. We revisit some high school math.

Every point in a two dimensional space can be represented as pair of coordinates, usually represented by x and y.

point p = (x, y)







I would like to touch python implementation in parallel here as well.

This point can be represented as python tuple of two floats and can be declared as :

p = (floatA, floatB)



To define a triangle, we need three points. Let’s call them a, b, c and define them as:

a = (x1, y1)

b = (x2, y2)

c = (x3, y3)

Now we define our test-point p as:

p = (x, y)



If we look at the point definitions above, these are nothing but 8 numbers(floats). We will do some calculations on them. Namely, addition, subtraction, multiplication and division and arrive at another number as a result of these operations. And we have our test result. It is as simple as that. Nothing more, nothing less. So now lets begin applying our logic.



Convexity

Our test requires us to examine the concept of concavity/convexity.



Convexity is defined as :

‘Having a surface or boundary that curves or bulges outward’



The word ‘concave’ has the word ‘cave’ inside it. So it has something to do with a cave. This is how I remembered it since high school. Very funny ! but useful.

Which of these two figures below you think represents a cave.

You are right, it’s fig b.



This is what a concave point is :



In the figure below point ‘p’ is concave to points ‘a’ and ‘b’, if we move from ‘a’ to ‘b’ looking towards the left of ‘a’. Note that we define left as the side of our choice to be considered ‘inside’.



Convex is nothing but opposite of concave.



Now that we have the idea what convexity is, we will exploit this concept in our logic. For our given triangle, we will check whether the point ‘p’ is concave to the three lines ‘ab’, ‘bc’ and ‘ca’.

If it is concave to all three of them then it is inside the triangle, else not.

We devised a way to check if a given point lies to the left or right of a line. Here, the right/left side of a line is determined by going from one point to another. If we go from a —-> b, then imagine a person standing on point ‘a’ and facing point ‘b’. All the point lying on the right side of this person are right and all points on the left side of this person are left.



Two Point Form Equation of  a Line

To do this, we make use of two-point-form of equation of a line:

y = y1 + [(x - x1) (y2 - y1) / (x2 - x1)]



Again going to python implementation, this could be easily written as

y = y1 + (   (x – x1) * (y2 – y1) / (x2 – x1) )

In the above the line is defined between the point (x1, y1) and point (x2, y2). The general point (x, y) represents any point on this line.



Now that we have solid formula to use, let’s apply this to our case. Given the three sides of the triangle ‘ab’, ‘bc’ and ‘ca’, we test whether our test-point point lies to the left or right to each of these lines.

To find whether the point lies to left or right, we take the x coordinate of point ‘p’ and put in it the two-point-form equation of the line.

This will give us the y coordinate of the point ‘p’ if it were on the line.

Next we check whether this y coordinate that we calculated is greater or smaller than the actual y coordinate of ‘p’. If it is greater than ‘p’ is on the left else it is on the right.







Let the points forming the line be ‘a’ and ‘b’ defined as:

a = (x1, y1)

b= (x2, y2)

and point ‘p’ as:

p = (x3,  y3)



Next we find the y coordinate if were to lie on ‘ab’,

this will given by:

y = y1 + [(x3 - x1) (y2 - y1) / (x2 - x1)]

Let’s take a simple view of the above equation. In the above equation we have five number on the right. x1, x2, x3, y1 and y2. We are doing simple operation of  +, – , x and / on them and we get a sixth number y. Now we just want to calculate whether y is greater than y3 or not. Simple, and we get the answer if lies on the left or right.

Also we want to be sure that we take all the cases in going from ‘a’ to ‘b’. Point ‘b’ could be in any quadrant relative to ‘a’. There are exactly four possibilities for ‘b’ lying in each quadrant.



If ‘b’ lies in quadrant ’0′ or ’3′ then we note that:

y > y3, ‘p’ is on right of ‘ab’

y < y3, ‘p’ is on left of ‘ab’



if ‘b’ is in quadrant ’1′ or ’2′ then the conditions are reversed.

y > y3, ‘p’ is on left of ‘ab’

y < y3, ‘p’ is on right of ‘ab’



So we have to check for ‘b’ position with respect to ‘a’. And then use that information along the comparisons to finally get the result.

Lets put the python implementation for this. This code is more verbose than what it should be. It could definitely be more concise. Parts of it are also redundant. But I wanted this to be more readable and hence the verbosity.


def isConvex(pointA, pointP, pointB):
    x1, y1 = pointA

    x2, y2 = pointB

    x3, y3 = pointP

    if x2 > x1 and y2 > y1:
        quadB = 0
    elif x2 < x1 and y2 > y1:
        quadB = 1
    elif x2 < x1 and y2 < y1:
        quadB = 2
    elif x2 > x1 and y2 < y1:
        quadB = 3

    y = y1 + ((x3 - x1) * (y2 - y1) / (x2 - x1))

    if quadB == 0 or quadB == 3:
        if y > y3:
            return True
        else:
            return False
    elif quadB == 1 or quadB == 2:
        if y > y3:
            return False
        else:
            return True



Following is the example of the above function at work.

a = (1.0, 6.0)
b = (3.0, 8.0)
p = (2.0, 12.0)

isConvex(a, p, b)
False

Now that we have a working function to test for convexity(‘right’). It is very easy to get all the three points of a triangle – ‘a’, ‘b’, ‘c’ and test a point – ‘p’ is inside or outside.

Let write the code for that:

def insideTriangle(a, b, c, p):
    if (not isConvex(a, p, b)) and (not isConvex(b, p, c)) and (not isConvex(c, p ,a)):
        return True
    else:
        return False

Please note that we are using the function isConvex() which we defined earlier.

And that’s it, we have our function to check whether the point lies in the triangle or not.



Now that  we know the concept of our test inside-out, let’s put it to a simple test. Please download the attached scene file and the script. There is a null called ‘p’ in the scene, that we test inside the triangle defined by three other nulls ‘a’, ‘b’ and ‘c’.



Here’s the final script to run the test inside the sample scene file

def getObjectByUserKeyword(inKeyword):
    oColl = Application.ActiveSceneRoot.FindChildren('')

    for o in oColl:
        keywordColl = Application.GetUserKeyword(o)
        for thisKeyword in keywordColl:
            if thisKeyword == inKeyword:
                return o

    return None

def getScenePoints():
    a = getObjectByUserKeyword('a')
    b = getObjectByUserKeyword('b')
    c = getObjectByUserKeyword('c')
    p = getObjectByUserKeyword('p')

    return a, b, c, p

def getPointCoordinates(inPoint):
    x = inPoint.Kinematics.Global.Parameters('PosX').Value
    y = inPoint.Kinematics.Global.Parameters('PosY').Value

    return x, y

def getPointCoordinateList(inList):
    coordinateList = []
    for point in inList:
        coordinateList.append(getPointCoordinates(point))

    return coordinateList

def setVisibility(on=True):
    inside = getObjectByUserKeyword('inside')
    outside = getObjectByUserKeyword('outside')

    inside.Properties('Visibility').Parameters('viewvis').Value = on
    outside.Properties('Visibility').Parameters('viewvis').Value = not on

    return

def isConvex(pointA, pointP, pointB):
    x1, y1 = pointA

    x2, y2 = pointB

    x3, y3 = pointP

    if x2 > x1 and y2 > y1:
        quadB = 0
    elif x2 < x1 and y2 > y1:
        quadB = 1
    elif x2 < x1 and y2 < y1:
        quadB = 2
    elif x2 > x1 and y2 < y1:
        quadB = 3

    y = y1 + ((x3 - x1) * (y2 - y1) / (x2 - x1))

    if quadB == 0 or quadB == 3:
        if y > y3:
            return True
        else:
            return False
    elif quadB == 1 or quadB == 2:
        if y > y3:
            return False
        else:
            return True

def insideTriangle(a, b, c, p):
    if (not isConvex(a, p, b)) and (not isConvex(b, p, c)) and (not isConvex(c, p ,a)):
        return True
    else:
        return False

scenePoints = getScenePoints()

a, b, c, p = getPointCoordinateList(scenePoints)

testValue = insideTriangle(a, b, c, p)

setVisibility(testValue)

To run the test:

1. Move the null ‘p’ , or any of the nulls ‘a’, ‘b’ and/or ‘c’  to make ‘p’ lie inside or outside the triangle in the front view. If you move the points ‘a’ , ‘b’ or ‘c’, please make sure that cyclic order ‘abc’ is maintained in the anticlockwise direction. This is important so that we always test for points on the left of line.

2. Run the script.

3. The text-curves ‘inside’ and ‘outside’ will be visible according the result of the test.



Note that, as we are testing in a 2D plane , we use the only the front view as our coordinate plane and the points have their position z = 0.



Enjoy !!



Download insideTriangleTest.scn



Making your PPG pretty – Part 02

Posted by Administrator | Posted in Python, SoftImage XSI | Posted on 11-04-2011

0

Go To : Making your PPG pretty – Part 01



In XSI PPGs it is not possible to change the look of the text that appears as labels for parameters. But we have a workaround. We can not only change the font, its size but we can also the color of the foreground and background. To achieve this we have to use the text editor widget.

Adding Text Editor Widget to your PPG





Below is the python code which  produces a Demo PPG. Please note that foreground and background color attributes require a hex color code. You can convert the color code from RGB (0 – 255) to hex color code through a number of websites. Here is a link. But doing some pretty basic math, you can create your own hex code. In the python example, I have written two functions to do exactly that. Please go through the code. Also note that I don’t like using the PPG logic passed on as a string. But for Demo Purpose I am setting the PPG Logic through a string. In your plugins, you have to simply set the logic attribute of your PPG to the plugin file itself. You can find more information regarding this on a nice post written by Andy Nicholas.



Just run this code in XSI and you will get the PPG as shown above. The buttons Chage FG and Change BG simply changes some default colors. While selecting the color from the color widgets will also update the foreground and background colors. I have just added three font types to play around with. You can set this to any standard font as you like. As explained in the last post Making Your PPG pretty – Part 1, the trick to make the background transparent is the same. You just set the background color to XSI default grey color. And yes you can be creative here as well. You can use  webdings or wingdings font type to get some graphics instead of fonts.

from win32com.client import constants as c

DEFAULT_BG_COLOUR = 0xA6A8AB # PPG Gray
DEFUALT_FG_COLOUR = 0x000000 # Black

def defineProp(inProp):
    dispText = inProp.AddParameter3('dispText', c.siString, 'My Text')
    dispText.ReadOnly = True

    inProp.AddParameter3('inText', c.siString, 'My Text')

    inProp.AddParameter3('bgColourInt', c.siInt2, 4)

    inProp.AddParameter3('fgColourInt', c.siInt2, 0)

    inProp.AddParameter3('font', c.siString, 'Arial Black')

    inProp.AddParameter3('rFg', c.siDouble, 0.000)
    inProp.AddParameter3('gFg', c.siDouble, 0.000)
    inProp.AddParameter3('bFg', c.siDouble, 0.000)

    inProp.AddParameter3('rBg', c.siDouble, 0.671)
    inProp.AddParameter3('gBg', c.siDouble, 0.659)
    inProp.AddParameter3('bBg', c.siDouble, 0.651)

    return prop

def definePropLayout(inProp):
    layout = inProp.PPGLayout
    layout.Language = 'Python'

    layout.AddSpacer(0, 20)

    layout.AddGroup('Text')
    dispText = layout.AddItem('dispText', '', c.siControlTextEditor)
    dispText.SetAttribute(c.siUINoLabel,True)
    dispText.SetAttribute(c.siUIFont, 'Arial Black')
    dispText.SetAttribute(c.siUIFontSize, 15)
    dispText.SetAttribute(c.siUIBackgroundColor, DEFAULT_BG_COLOUR)
    dispText.SetAttribute(c.siUIForegroundColor, DEFUALT_FG_COLOUR)
    dispText.SetAttribute(c.siUIHorizontalScroll, False)
    dispText.SetAttribute(c.siUIVerticalScroll, False)
    dispText.SetAttribute(c.siUIVerticalScroll, False)
    dispText.SetAttribute(c.siUIHeight, 45)
    dispText.SetAttribute(c.siUIMarginWidth,5)

    layout.EndGroup()

    layout.AddSpacer(0, 20)

    layout.AddGroup('Text Attributes')
    layout.AddSpacer(0, 20)

    layout.AddItem( 'inText', 'Enter Text', c.siControlString)

    fontList = ['Arial Black', 'Arial Black',
                'Times New Roman', 'Times New Roman',
                'Comic Sans', 'Comic Sans']
    layout.AddEnumControl('font', fontList, 'Select Font')

    layout.AddSpacer(0, 20)

    layout.EndGroup()

    layout.AddSpacer(0, 40)

    layout.AddRow()
    btnChangeFG = layout.AddButton('changeFG', 'Change FG')
    btnChangeFG.SetAttribute(c.siUICX, 150)
    btnChangeFG.SetAttribute(c.siUICY, 50)

    btnChangeBG = layout.AddButton('changeBG', 'Change BG')
    btnChangeBG.SetAttribute(c.siUICX, 150)
    btnChangeBG.SetAttribute(c.siUICY, 50)

    btnSetDefaultColours = layout.AddButton('setDefault', 'Set Defaults')
    btnSetDefaultColours.SetAttribute(c.siUICX, 150)
    btnSetDefaultColours.SetAttribute(c.siUICY, 50)

    layout.EndRow()

    layout.AddSpacer(0, 40)

    layout.AddColor('rFg', 'FG Color')

    layout.AddColor('rBg', 'BG Color')

    logicStr = """
from win32com.client import constants as c

def changeFG_OnClicked():
    prop = PPG.Inspected(0)
    layout = PPG.PPGLayout

    currentFGColourIndex = prop.fgColourInt.value
    currentBGColourIndex = prop.bgColourInt.value

    colourIndex = currentFGColourIndex + 1

    if colourIndex == currentBGColourIndex or colourIndex > 4:
        colourIndex += 1
        if colourIndex > 4:
            colourIndex = 0
            if colourIndex ==  currentBGColourIndex:
                colourIndex += 1

    colours = [0x000000, 0xB5F669, 0x149FF0, 0x8069F6, 0xA6A8AB]
    colour = colours[colourIndex]
    dispText = layout.Item('dispText')
    dispText.SetAttribute(c.siUIForegroundColor, colour)

    prop.fgColourInt.value = colourIndex

    PPG.Refresh()

    return

def changeBG_OnClicked():
    prop = PPG.Inspected(0)
    layout = PPG.PPGLayout

    currentFGColourIndex = prop.fgColourInt.value
    currentBGColourIndex = prop.bgColourInt.value

    colourIndex = currentBGColourIndex + 1

    if colourIndex == currentFGColourIndex or colourIndex > 4:
        colourIndex += 1
        if colourIndex > 4:
            colourIndex = 0
            if colourIndex ==  currentFGColourIndex:
                colourIndex += 1

    colours = [0x000000, 0xB5F669, 0x149FF0, 0x8069F6, 0xA6A8AB]
    colour = colours[colourIndex]
    dispText = layout.Item('dispText')
    dispText.SetAttribute(c.siUIBackgroundColor, colour)

    prop.bgColourInt.value = colourIndex

    PPG.Refresh()

    return

def inText_OnChanged():
    prop = PPG.Inspected(0)
    prop.dispText.Value = str(prop.inText.Value)
    PPG.Refresh()

    return

def font_OnChanged():
    prop = PPG.Inspected(0)
    layout = PPG.PPGLayout

    dispText = layout.Item('dispText')
    dispText.SetAttribute(c.siUIFont, prop.font.Value)
    PPG.Refresh()

    return

def setDefault_OnClicked():
    layout = PPG.PPGLayout
    prop = PPG.Inspected(0)

    prop.dispText.Value = 'My Text'
    prop.inText.Value = 'My Text'

    prop.rFg.Value = 0.0
    prop.gFg.Value = 0.0
    prop.bFg.Value = 0.0

    prop.rBg.Value = 0.671
    prop.gBg.Value = 0.659
    prop.bBg.Value = 0.651

    dispText = layout.Item('dispText')
    dispText.SetAttribute(c.siUIBackgroundColor, 0xA6A8AB)
    dispText.SetAttribute(c.siUIForegroundColor, 0x000000)
    dispText.SetAttribute(c.siUIFont, 'Arial Black')

    prop.fgColourInt.Value = 0
    prop.bgColourInt.Value = 4

    PPG.Refresh()

def rFg_OnChanged():
    _updateColour(1)
    return

def gFg_OnChanged():
    _updateColour(1)
    return

def bFg_OnChanged():
    _updateColour(1)

    return

def rBg_OnChanged():
    _updateColour(0)
    return

def gBg_OnChanged():
    _updateColour(0)
    return

def bBg_OnChanged():
    _updateColour(0)

    return

def _updateColour(fg):
    prop = PPG.Inspected(0)

    if fg:
        r = prop.rFg.Value
        g = prop.gFg.Value
        b = prop.bFg.Value
    else:
        r = prop.rBg.Value
        g = prop.gBg.Value
        b = prop.bBg.Value

    r, g, b = denormalizeRGB(r, g, b)

    hex = rgbToHex(r, g, b)

    layout = PPG.PPGLayout
    dispText = layout.Item('dispText')

    if fg:
        dispText.SetAttribute(c.siUIForegroundColor, hex)
    else:
        dispText.SetAttribute(c.siUIBackgroundColor, hex)

    PPG.Refresh()

    return

def denormalizeRGB(r, g, b):
    r = int(round(r * 255, 0))
    g = int(round(g * 255, 0))
    b = int(round(b * 255, 0))

    return r, g, b

def rgbToHex(r, g, b):
    hexString = '0123456789ABCDEF'
    remR = r % 16
    divR = r / 16
    rHex = '%s%s'%(hexString[divR], hexString[remR])

    remG = g % 16
    divG = g / 16
    gHex = '%s%s'%(hexString[divG], hexString[remG])

    remB = b % 16
    divB = b / 16
    bHex = '%s%s'%(hexString[divB], hexString[remB])

    hex = eval('0x%s%s%s'%(bHex, gHex, rHex))

    return hex

"""

    layout.Logic = logicStr

    return prop

prop = XSIFactory.CreateObject('CustomProperty')
prop.Name = 'myProp'
prop = defineProp(prop)
prop = definePropLayout(prop)
Application.InspectObj(prop, '', 'MyProperty')







Making your PPG pretty – Part 01

Posted by Administrator | Posted in Python, SoftImage XSI | Posted on 05-04-2011

0

Go To : Making your PPG pretty – Part 02

PPG’s provide GUI for users to interact with your plugins/tools/script. They are a mini-application, if you may. So why not make your mini-application look cool. Here is how you can make your PPG prettier.

Adding Images/Logos to your PPG

You can change this boring PPG,







to this,



Please note that you can add only .bmp formats. So how do we get the transparency with .bmp, hmmm, elementary my dear Watson. The trick is to use the background color of image file same as that of your PPG.



To do that open Softimage and take a capture the screen. In photoshop or any other image editing software bring in the capture and set the bg color to the softimage application window color from the capture.



Remember, the color varies from monitor to monitor and profile to profile. So to make sure this works on all the calibrations, use the same monitor and color profile from which you capture and make your logo.



Just clean your image off any background and use the background created from the capture.





Save your image as .bmp and you are done.

You can add company/studio logo to the PPG,  image files as bullets for parameters, signature etc., the possibilities are endless.



You can set images to your PPG  by using the c.siControlBitmap item type . All it needs is a path to a .bmp file. Here’s equivalent python code.

from win32com.client import constants as c

LOGO_PATH = r'---path to your .bmp file here---'

def defineProp(inProp):
 inProp.AddParameter3('logo', c.siString)
 inProp.AddParameter3('myParam', c.siDouble)
 inProp.AddParameter3('anotherParam', c.siBool)

 return prop

def definePropLayout(inProp):
 layout = inProp.PPGLayout
 logo = layout.AddItem('logo','',c.siControlBitmap)
 logo.SetAttribute(c.siUIFilePath,  LOGO_PATH)
 logo.SetAttribute(c.siUINoLabel, True)

 layout.AddSpacer(0, 20)

 layout.AddGroup('My Parameters')
 layout.AddSpacer(0, 10)
 layout.AddItem('myParam','A Parameter')
 layout.AddSpacer(0, 5)
 layout.AddItem('anotherParam','Another Parameter')
 layout.AddSpacer(0, 5)
 layout.EndGroup()
 layout.AddSpacer(0, 20)

 return prop

prop = XSIFactory.CreateObject('CustomProperty')
prop.Name = 'myProp'
prop = defineProp(prop)
prop = definePropLayout(prop)
Application.InspectObj(prop, '', 'MyProperty', c.siModal, False)

Some other characters

Posted by Administrator | Posted in Art | Posted on 03-04-2011

0

Old forgotten stuff, extracted from the HDD

Just another paint session

Posted by Administrator | Posted in Art | Posted on 03-04-2011

0

This accounts for most of the Saturday. Still a work in progress.

Some props . . .

Posted by Administrator | Posted in Modelling, Props | Posted on 28-03-2011

0

A few props for one of the old projects

And more heads . . .

Posted by Administrator | Posted in Heads, Modelling | Posted on 28-03-2011

0

Here are some more heads done a few years ago,
